| Standard Parts |
| General Specifications |
| Operating system | Android 4.4 embedded OS |
| CPU | 1.2GHz |
| RAM | RAM 1G; FLASH 8G |
| Ports | One USB 2.0 port(OTG supports U Flash Disk, Mouse, 100M ethenet), one charging mouth, one TF card(128G), one SIM card |
| Protection Grade |
| Industrial ProtectionGrade | IP65 |
| Drop Grade | Drop resistance from 1.2m |
| Wireless Communication |
| Bluetooth | V4.0 |
| GPS | Built-in Beidou/GPS/GLONASS; supports A-GPS; External Beidou/GPS/GLONASS; supports RTCM 2.3 differential data |
| WIFI | Support IEEE 802.11b/g/n |
| 4G | FDD/WCDMA/GSM
LTE_FDD B1/B3/B7 LTE_TDD B41/B40
WCDMA B1//B2/B5
GSM 900/1800/1900 |
| Data Acquisition (Optional) |
| Fingerprint Identification | Supports fingerprint entry, image collection, fingerprint recognition, fingerprint deletion etc.
Type: TCSIST semiconductor sensor
Acquisition window size: 24.5*19mm
Effective image size:15.5*18.5mm
Sensor type: capacitive
Image size: 256*360
Resolution: 500 DPI
Matching mode: contrast mode(1:1); search mode(1:N) |
| Barcode Scanning
| 1D Infrared Scanner Index:
Scanning speed: 50 times/second
Scanning distance: 5.7cm-60.96cm |
| 1D Laser Scanner Index:
Scanning speed: 104 times/second+12 times/second (two way scanning)
Scanning distance: 2.5cm-114.3cm |
| 2D Barcode Scanner Index:
Scanning speed: 10 times/second
Depth of field: 5cm-30cm |
| RFID | LF RFID:
134KHZ LF RFID or 124KHZ LF RFID
Identification distance: 0-3 cm |
| NFC (HF) RFID:
Working frequency: 13.56MHZ
Profile: Support ISO/IEC 15693, ISO/IEC 14443A profile
Support Cards: SR176, SRIX4K (TYPE-B), I- Code2, TI RFID label-it HF-I, EM4034, Mifare Classic ETC
Identification distance: not more than 5cm |
| UHF RFID:
Working frequency: 840-960MHz(customization of requiredfrequency band)
Support agreement: EPC C1 GEN2/ISO 18000-6C /ISO18000-6B
Output power: 10dBm-30dBm
Identification distance: not more than 6m |
| Physical Layer Parameter |
| Display Screen | 4 inch LCD screen, 480x800 IPS screen, capacitive touch screen |
| Touch screen | Thicken tempered glass(thickness 1mm); supports 10 points touch and double-click for waking up |
| Keyboard | Physical keypad with 19 phiscal keys |
| Camera | 8.0 million pixels; support auto focus and fill-flash function. |
| Headset | Supports standard headset, Bluetooth headset; support Mike and receiver function |
| Vibration Function | Vibrating prompt function |
| Sensor | Supports light sensation, gyroscope, compass, gravity |
| Flashlight Function | Used for emergency lighting |
| Rechargeable LithiumBattery | 3.7V, 3800mAh |
| Handle Battery | 3.7V, 5000mAh |
| Standby | The standby current is less than 10mA |
| Dimension | 168mm*75mm*26mm |
| Weight | 350g |
| Environmental characteristics |
| Working Temperature | -20℃ ~ +50℃ |
| Storage Temperature | -40℃ ~ +60℃ |
| Humidity | 5%-95% relative humidity; no condensation |
